SR100SX

Inner rotor 36v 250w hub motor for electric bike

  • Position::rear/cassette
  • Dropout::138mm/142mm
  • Brake Type::V/ Disk brake
  • Rated Voltage::36V/48V
  • Rated Power::250W
  • Max Speed::25KM/H
  • Max Torque::50N.m
  • Efficiency::≥80%
  • Weight::2kg
  • Wheel Size::20-28"
  • Spoke Items::36H-13G
  • Freewheel::8-10S cassette
  • Noise Grade::≤55DB
  • IP Grade::IP65
  • Product Details

    AKM 100SX rear cassette 250 watt high torque hub bldc motor powerful 250 watts hub motor gear electric bicycle 20" 36 48v 250w thumb throttle e-bike wheel motor kit for e cycle


    MOTOR 36V 250W double gear brushless hub motor, Waterproof 9 pins of motor cable
    Rim16-29'' rim and spokes assemble as default
    Batterylithium-ion battery, All battery including fuse and BMS
    Controller36v 14a/17a standarded square wave or sine wave controller for choose
    PAS8/10/12 magnets PAS, Torque sensor for optional
    DisplayLED /LCD Display for option
    ThrottleThumb throttle/Twist throttle for option
    BrakingE-brakes levers OR E-brake sensor for motor power cut off
    wiringWaterproof harness or regular connection(Bullet/PP30 for motor and JST/DJ2.8 for other electric parts)
